SkyRC FuriaX Maxi 1S Sensored ESC

Size and Weight

Size: 34 x 34 x 15.7 mm
* Includes a 6.0 mm wire connection board protrusion.
Weight: Approx. 27.9g

TechSpec

Constant/Burst Current: 100A/360A
Compatible Motor: Brushless Sensored & Sensorless Motor
Compatible Car: 1/12^th Touring Car
Battery Cell Count: 1S LiPo

BEC Output: 6V/7.4V
Low Voltage Protection: 0(OFF), 2.0~3.90V, step 0.10V
Over-temperature Protection: off / 95°C / 105°C / 130°C , default: 105°C
Cooling: Fan
Firmware: Supported

Working and Storage

Operating temperature: 0℃~40℃
Operating humidity: 10％~90%
Storage temperature: -10℃~50℃
Storage humidity: 20％~65%
