EXTRA 300 76cc gas Wingspan: 2260 mm

Calculate Shipping

Fixed Rate By Invoice Total - $19.99
FIXED RATE SHIPPING (EXCLUDING DANGEROUS GOODS , AIRCRAFT KITS , 1/5 SCALE CARS, DISPLAY STANDS & OVER LENGTH ITEMS )

Free pick-up from store - $0.00
Warehouse pick available

Description
Specifications

EXTRA 300
Item code: BH194

SPECIFICATION:
– Wingspan: 2260 mm (89 in).
– Length: 2250 mm (88.5 in).
– Weight: 8.5 kg (18.74lbs).
– Wing area: 87.9 dm².
– Wing loading: 96.7 g/dm².
– Servo mount: 42mm x 21mm.
– Wing type: Naca Airfoil.
– Spinner : 95mm (included).
– Gear type: Carbon fiber for main gear (included) and Carbon fiber tail gear (included).
– Covering type: Genuine oracover.

Parts listing required (not included):
– Radio: 06 channels minimum.
– Servo: 06 servos (HV High torque steel gear servo).
– Engine: 76cc gas.
– Motor: Brushless outrunner 5000 – 6500W, 230KV.
– Propeller: Suit with your engine.

Recommended Motor and Battery set up (not included):
– Motor: RIMFIRE 60cc.
– Lipo cell: 12 cells 5,000-7,000mAh.
– Receiver battery: 6-7.4V/ 2200-3200mAh Lipo.
– ESC: 120A.
– Torque servos: 30kg/cm – 40kg/cm.

ALL BALSA – PLY WOOD CONSTRUCTION.
COVERED WITH ORACOVER

(BH-194)
