RC4WD 1/10 Warn 8274 Winch (75th Anniversary Edition)

RC4WD 1/10 Warn 8274 Winch (75th Anniversary Edition)





Introducing our all-new RC4WD 1/10 Warn 8274 Winch (75th Anniversary Edition). This winch brings a realistic, licensed 1/10 version of the custom-configured M8274 Warn Winch! The design is made from quality materials and craftsmanship! This winch is packed full of great features including heavy-duty pulling strength, a free spool, and ultra-realism.





Specifications:

• CNC Machined
• Billet and Cast Aluminum
• Working Spring Loaded Warn Hook
• Synthetic Winch Rope
• Highly Detailed
• Free Spool
• Full Warn Decals Installed
• Rated Voltage: 6V
• Operating Voltage: 6V - 12.4V
• Can operate on 3 Cell Lipo
• 3.28ft / 1.0m Rope Pre-Installed
• Load Limits: Dead Lift 50lbs / 22.6kgs
• Load Limits: Rolling Drag 70lbs / 31.7kgs
• Winch Rope Load Limits: Dead Lift 25lbs / 11.3kgs
• Winch Rope Load Limits: Rolling Drag 37lbs / 16.8kgs
• 30 Day Warranty
• Length: 2.56in / 65.0mm
• Width: 1.06in / 27.0mm
• Height: 1.77in / 45.0mm
• Weight: 4.23oz / 120g















Shown installed on RC4WD Gelande II RTR Truck w/Cruiser Body Set (Red) (Z-RTR0047) for example (Not Included)







What's Included:

• 1x RC4WD 1/10 Warn 8274 Winch (75th Anniversary Edition)
• 4x M2.5 x 4mm SHCS (Black)
• 4x M2.5 x 6mm SHCS (Black) (Z-S0855)
• 1x RC4WD Warn Winch Pull Tags (Z-S1660)
• 1x Warn Decal Sheet Set



Required Parts:

• RC4WD Warn 1/10 Advanced Wireless Remote/Receiver Winch Controller Set (Z-E0130)
• RC4WD Wired Winch Control Unit (Z-S1089)
