| Type |
| Scale |
1/10th |
| Brushed/Brushless |
BL |
| Sensored/Sensorless |
SD |
| Waterproof |
No |
|
| Specifications |
| Cont./Peak Current |
100A/500A |
| Input Voltage |
2S Lipo |
| BEC BEC Output |
Switch Mode 6V/7.4V @5A |
|
| Wires & Connectors |
| Input Wires |
Black-13AWG-200MMmm*2 |
| Output Wires |
Black-13AWG-200MMmm*3 |
| Input Connectors |
No |
| Output Connectors |
No |
|
| Fan |
| Size |
20*20*8mm |
| Voltage Range |
5-7.4V |
| Powered by |
BEC |
|
| ESC Programing via |
| SET Button on ESC |
Not Supported |
| LED Program Box |
Not Supported |
| LCD G2 Program Box |
Supported |
| LCD PRO |
Supported |
| OTA Programmer |
Supported |
| Program Port |
Separate Program Port |
|
| Data Recording |
| Extreme value |
Supported |
| Real-time Data |
Supported |
| Historical data (Graph) |
Supported |
|
| Firmware |
| Firmware Upgrade |
Supported |
|
| Size & Weight |
| Size |
34.8*30*13.8mm |
| Weight |
63g(w/Wires) |
|
| Applications |
| Motors |
3650 size motors |
| Vehicles |
Stock Class of 1/10th Touring Car and Buggy Racing, 1/10th Drift |
| KV Rating/T Count |
≥10.5T |
|
