| Product Number |
|
| Type |
| Scale |
1/10th |
| Brushed/Brushless |
Brushless |
| Sensored/Sensorless |
Sensored |
| Waterproof |
NO |
|
| Specifications |
| Cont./Peak Current |
200A/1200A |
| Input Voltage |
2S Lipo |
| BEC BEC Output |
Switch Mode 5V-7.4V @5A |
|
| Wires & Connectors |
| Input Wires |
Black-10AWG-200MMmm*1 Black-10AWG-200MMmm*1 |
| Output Wires |
Black-10AWG-200MMmm*3 |
| Input Connectors |
No |
| Output Connectors |
No |
|
| ESC Programing via |
| SET Button on ESC |
Not Supported |
| LED Program Box |
Not Supported |
| LCD G2 Program Box |
Supported |
| LCD PRO |
Supported |
| OTA Programmer |
Supported |
| Program Port |
Separate |
|
| Data Recording |
| Extreme value |
Supported |
| Real-time Data |
Supported |
| Historical data (Graph) |
Supported |
|
| Firmware |
| Firmware Upgrade |
Supported |
|
| Size & Weight |
| Size |
37.7*37.2*33.2mm |
| Weight |
137g (Included wires&connectors) |
|
| Applications |
| Motors |
SD BL Motors |
| Vehicles |
1/10th Drag Racing |
| KV Rating/T Count |
XERUN 3652/3662 DRX |
|
