| Product Number |
|
| Type |
| Brushed/Brushless |
BL |
| High Voltage/Regular |
Regular |
|
| Specifications |
| Cont./Peak Current |
150A/180A |
| Input Voltage |
3-8S Lipo |
| BEC Output |
Switch Mode:5-12V & Cont. 10A，Peak 30A |
|
| Wires & Connectors |
| Input Wires |
Red-10AWG-150mm*1/Black-10AWG-150mm*1 |
| Output Wires |
Black-12AWG-100mm*3 |
| Input Connectors |
No |
| Output Connecotors |
4.0mm Gold Connectors (Female) |
|
| ESC Programing via |
| Transmitter |
Not Support |
| LED Program Card |
Not Support |
| LED Program Box |
Not Support |
| LCD Program Box |
Supported |
| OTA Programmer |
Supported |
| Program Port |
Separate Program Port |
|
| Firmware |
| Firmware Upgrade |
Supported |
|
| Telemetry Function |
| |
Mikado VBar；Futaba S.Bus2；etc. |
|
| Size & Weight |
| Size |
83.2*37.1*22.5mm (without fan) |
| Weight |
150.4g (with wires, no fan) |
|
| Application scope |
| |
520-580 class electric helicopter (main blade length 520-580mm),or fixed-wing |
|
